TYPE SV-17

* Secondary coil voltage more than 17 kV
* Very rapid build-up of secondary voltage
* Start-up revolution speed 500 rpm
* Maximum revolution speed 15,000 rpm
* Operational temperature range between -20°C and +60°C
* Storage temperature range between -40°C and +100°C




TYPE SV-17


chain saw

The SV-17 electronic ignition module is designed to achieve contact-free ignition of air-fuel mixtures. This type of ignition module utilises transistor switches for magnet activation. The modules are fabricated to high standards at VEC’s own modern production facility. VEC uses only high-quality components from globally established suppliers. It all adds up to a long lifetime and reliable operation.

The SV-17 module matches the original ignition module type 1130 400 1300 supplied by STIHL. SV-17 is specified for installation in STIHL Chain saw model 017.

All products supplied by VEC Ignitions are covered by a five-year warranty. This warranty does not cover damages resulting from improper installation and damages caused by mechanical actions.

When ordering an ignition module or component, make sure to specify the correct model designation, in this case SV-17. Please let us know if you intend to operate the modules under extreme temperature conditions. We have special solutions for these cases.

Refer to the package specification page at the end of this catalogue.The electronic ignition module comes in a blister package (see sketch S1) along with a high voltage cable and an ignition breaker cable. Larger quantities of the SV-17 module come in appropriately sized cartons (see sketches S2, S3, and S4).
